At TFE – Transmission & Fluid Equipment we stock Brennan hydraulic adapters. The tables below show the styles and sizes we commonly stock. If you require a style or size not shown, please call our Customer Service Department for pricing and availability.

JIC Straight Tube Union 2403 Series

JIC Straight Tube Union 2403 Series

wdt_ID Part # Tube OD Thread B1 Thread B2 Length L Hex C
1 2403-04-04 1/4 7/16-20 7/16-20 1.375 1/2
2 2403-05-04 5/16 1/4 1/2-20 7/16-20 1.375 9/16
3 2403-05-05 5/16 1/2-20 1/2-20 1.375 9/16
4 2403-06-04 3/8 1/4 3/4-16 7/16-20 1.406 5/8
5 2403-06-06 3/8 9/16-18 9/16-18 1.406 5/8
6 2403-08-04 1/2 1/4 3/4-16 7/16-20 1.51 13/16
7 2403-08-06 1/2 3/8 3/4-16 9/16-18 1.515 13/16
8 2403-08-08 1/2 3/4-16 3/4-16 1.625 13/16
9 2403-10-06 5/8 3/8 7/8-14 9/16-18 1.68 15/16
10 2403-10-08 5/8 1/2 7/8-14 3/4-16 1.781 15/16
11 2403-10-10 5/8 7/8-14 7/8-14 1.875 15/16
12 2403-12-08 3/4 1/2 1 1/16-12 3/4-16 1.953 1 1/8
13 2403-12-10 3/4 5/8 1 1/16-12 7/8-14 2.046 1 1/8
14 2403-12-12 3/4 1 1/16-12 1 1/16-12 2.156 1 1/8
15 2403-14-14 7/8 1 3/16-12 1 3/16-12 2.218 1 1/4
16 2403-16-12 1 3/4 1 5/16-12 1 1/16-12 2.21 1 3/8
17 2403-16-16 1 1 5/16-12 1 5/16-12 2.25 1 3/8
18 2403-20-16 1 1/4 1 1 5/8-12 1 5/16-12 2.38 1 11/16
19 2403-20-20 1 1/4 1 5/8-12 1 5/8-12 2.437 1 11/16
20 2403-24-20 1 1/2 1 1/4 1 7/8-12 1 5/8-12 2.62 2
21 2403-24-24 1 1/2 1 7/8-12 1 7/8-12 2.75 2
22 2403-32-32 2 2 1/2-12 2 1/2-12 3.406 2 5/8

JIC Tube Elbow-90 º 2500 Series

JIC Tube Elbow-90 º 2500 Series

wdt_ID Part # Tube OD Thread B1 & B2 Length M1 & M2 Square Y
1 2500-04-04 1/4 7/16-20 0.89 1/2
2 2500-05-05 5/16 1/2-20 0.953 9/16
3 2500-06-06 3/8 9/16-18 1.062 5/8
4 2500-08-08 1/2 3/4-16 1.25 13/16
5 2500-10-10 5/8 7/8-14 1.453 15/16
6 2500-12-12 3/4 1 1/16-12 1.656 1 1/8
7 2500-14-14 7/8 1 3/16-12 1.8 1 1/4
8 2500-16-16 1 1 5/16-12 1.812 1 3/8
9 2500-20-20 1 1/4 1 5/8-12 2.062 1 3/4
10 2500-24-24 1 1/2 1 7/8-12 2.328 2
11 2500-32-32 2 2 1/2-12 3.062 2 5/8

JIC Tube Elbow-45 º 2504 Series

JIC Tube Elbow-45 º 2504 Series

wdt_ID Part # Tube OD Thread B1 & B2 Length M1 & M2 Hex C
1 2504-04-04 1/4 7/16-20 0.81 1/2
2 2504-06-06 3/8 9/16-18 0.91 5/8
3 2504-08-08 1/2 3/4-16 1.13 13/16
4 2504-10-10 5/8 7/8-14 1.26 15/16
5 2504-12-12 3/4 1 1/16-12 1.28 1 1/8

JIC Tube Tee 2603 Series

JIC Tube Tee 2603 Series

wdt_ID Part # Tube OD Thread B1, B2 & B3 Length M1 & M2 Square Y
1 2603-04-04-04 1/4 7/16-20 0.89 1/2
2 2603-05-05-05 5/16 1/2-20 0.953 9/16
3 2603-06-06-06 3/8 9/16-18 1.062 5/8
4 2603-08-08-08 1/2 3/4-16 1.25 13/16
5 2603-10-10-10 5/8 7/8-14 1.453 15/16
6 2603-12-12-12 3/4 1 1/16-12 1.656 1 1/8
7 2603-16-16-16 1 1 5/16-12 1.812 1 3/8
8 2603-20-20-20 1 1/14 1 5/8-12 2.062 1 3/4
9 2603-24-24-24 1 1/2 1 7/8-12 2.328 2
10 2603-32-32-32 2 2 1/2-12 3.062 2 5/8

JIC Tube Cross 2650 Series

JIC Tube Cross 2650 Series

wdt_ID Part # Tube OD Thread B1, B2, B3 & B4 Length M Square Y
1 2650-04-04-04-04 1/4 7/16-20 0.89 1/2
2 2650-05-05-05-05 5/16 1/2-20 0.953 9/16
3 2650-06-06-06-06 3/8 9/16-18 1.062 5/8
4 2650-08-08-08-08 1/2 3/4-16 1.25 13/16
5 2650-10-10-10-10 5/8 7/8-14 1.453 15/16
6 2650-12-12-12-12 3/4 1 1/16-12 1.656 1 1/8
7 2650-16-16-16-16 1 1 5/16-12 1.812 1 3/8
8 2650-20-20-20-20 1 1/14 1 5/8-12 2.062 1 3/4
9 2650-24-24-24-24 1 1/2 1 7/8-12 2.328 2
10 2650-32-32-32-32 2 2 1/2-12 3.062 2 5/8

JIC Bulkhead Tube Union 2700 Series

JIC Bulkhead Tube Union 2700 Series

wdt_ID Part # Tube OD Thread B1 & B2 Length L Length L1 Hex C
1 2700-04-04 1/4 7/16-20 2.078 1.203 11/16
2 2700-05-05 5/16 1/2-20 2.078 1.203 3/4
3 2700-06-06 3/8 9/16-18 2.187 1.281 13/16
4 2700-08-08 1/2 3/4-16 2.437 1.437 1
5 2700-10-10 5/8 7/8-14 2.734 1.578 1 1/8
6 2700-12-12 3/4 1 1/16-12 3.093 1.75 1 3/8
7 2700-16-16 1 1 5/16-12 3.14 1.75 1 5/8
8 2700-20-20 1 1/14 1 5/8-12 3.312 1.796 1 7/8
9 2700-24-24 1 1/2 1 7/8-12 3.515 1.812 2 1/8
10 2700-32-32 2 2 1/2-12 4.203 2.093 2 3/4

JIC Bulkhead Tube Elbow-90 º 2701 Series

JIC Bulkhead Tube Elbow-90 º 2701 Series

wdt_ID Part # Tube OD Thread B1 & B2 Length M Length L Square Y
1 2701-04-04 1/4 7/16-20 0.968 1.56 1/2
2 2701-05-05 5/16 1/2-20 1.06 1.625 9/16
3 2701-06-06 3/8 9/16-18 1.093 1.812 5/8
4 2701-08-08 1/2 3/4-16 1.359 2.109 13/16
5 2701-10-10 5/8 7/8-14 1.562 2.39 15/16
6 2701-12-12 3/4 1 1/16-12 1.781 2.671 1 1/8
7 2701-16-16 1 1 5/16-12 1.937 2.796 1 3/8
8 2701-20-20 1 1/14 1 5/8-12 2.171 3.125 1 3/4
9 2701-24-24 1 1/2 1 7/8-12 2.343 3.421 2

JIC Bulkhead Tube Elbow-45 º 2702 Series

JIC Bulkhead Tube Elbow-45 º 2702 Series

wdt_ID Part # Tube OD Thread B1 & B2 Length M Length L Hex C
1 2702-04-04 1/4 7/16-20 0.718 1.53 1/2
2 2702-05-05 5/16 1/2-20 0.765 1.66 9/16
3 2702-06-06 3/8 9/16-18 0.828 1.671 5/8
4 2702-08-08 1/2 3/4-16 0.984 1.937 13/16
5 2702-10-10 5/8 7/8-14 1.109 2.171 15/16
6 2702-12-12 3/4 1 1/16-12 1.281 2.437 1 1/8
7 2702-16-16 1 1 5/16-12 1.468 2.562 1 3/8
8 2702-20-20 1 1/14 1 5/8-12 1.593 2.656 1 3/4
9 2702-24-24 1 1/2 1 7/8-12 1.781 2.671 2

JIC Bulkhead Branch Tee 2703 Series

JIC Bulkhead Branch Tee 2703 Series

wdt_ID Part # Tube OD Thread B1, B2 & B3 Length M Length L Square Y
1 2703-04-04-04 1/4 7/16-20 0.968 1.593 1/2
2 2703-05-05-05 5/16 1/2-20 1.06 1.72 9/16
3 2703-06-06-06 3/8 9/16-18 1.093 1.812 5/8
4 2703-08-08-08 1/2 3/4-16 1.359 2.109 13/16
5 2703-10-10-10 5/8 7/8-14 1.562 2.39 15/16
6 2703-12-12-12 3/4 1 1/16-12 1.781 2.671 1 1/8
7 2703-16-16-16 1 1 5/16-12 1.937 2.796 1 3/8
8 2703-20-20-20 1 1/14 1 5/8-12 2.171 3.125 1 3/4

JIC Bulkhead Run Tee 2704 Series

JIC Bulkhead Run Tee 2704 Series

wdt_ID Part # Tube OD Thread B1, B2 & B3 Length M Length L Square Y
1 2703-04-04-04 1/4 7/16-20 0.968 1.593 1/2
2 2703-05-05-05 5/16 1/2-20 1.06 1.72 9/16
3 2703-06-06-06 3/8 9/16-18 1.093 1.812 5/8
4 2703-08-08-08 1/2 3/4-16 1.359 2.109 13/16
5 2703-10-10-10 5/8 7/8-14 1.562 2.39 15/16
6 2703-12-12-12 3/4 1 1/16-12 1.781 2.671 1 1/8
7 2703-16-16-16 1 1 5/16-12 1.937 2.796 1 3/8
8 2703-20-20-20 1 1/14 1 5/8-12 2.171 3.125 1 3/4
